The Model 4704 features a PPS flow body and a stainless steel sensor. These compact electromagnetic flow meters excel in measuring conductive liquid flow rates from as low as 10 mL/min up to 16 L/min across a wide range of mediums. The COBALT series flow meter has the capability to operate independently of liquid properties such as density, viscosity, and temperature.
McMillan Flow Products introduces the COBALT Series: Electromagnetic flow meters for use with conductive liquids. These compact meters excel in measuring flow rates from as low as 10 mL/min up to 16 L/min across a wide range of mediums. The COBALT series flow meter has the capability to operate independently of liquid properties such as density, viscosity, and temperature. It is offered in both PPS and PVDF plastics. This offers versatility and cost savings to customers across a wider variety of applications.
The absence of moving parts in the COBALT series sensor technology offers enhanced long-term reliability, reduced maintenance, and consistent uninterrupted operation. Packaged in a compact design, the COBALT series electromagnetic flow meter is a space-efficient and cost-effective solution that enables easy integration into equipment while minimizing installation complexity.
The COBALT flow meter can support ranges as low as 10 – 500 mL/min and as high as 1 – 16 L/min.
Options for frequency pulse or analog 4-20 mA are available.
Units come standard with a 4-Pin Micro DC (M12) connection. Optional mating cables with various lengths are available.
The COBALT’s accuracy is ± 2% of full scale with ± 1% full scale repeatability. Minimum of 30 µS/cm for 3L | 10L | 16L units is required. Minimum of 200 µS/cm for 500M | 1L units is required.
500M | 1L | 3L units come with 1/4” FNPT connections. 10L | 16L units come with 3/8” FNPT connections. Options for various tube connections in several materials are available.
All units feature an integrated mounting bracket.
FITTINGS
ELECTRICAL CONNECTION
MOUNTING BRACKET
± 2.0% of full scale
± 1.0% of full scale
Minimum of 30 μS/cm for 3L | 10L | 16L units is required
Minimum of 200 μS/cm for 500M | 1L units is required
Inlet = 3x pipe diameters
Outlet = 2x pipe diameters
-4 to 140 °F [ -20 to 60 °C ]
14 to 140 °F [ -10 to 60 °C ]
145 psig [ 10 barg ]
3.7 psig [ 0.26 barg ] at full scale
20 cSt
PPS
316L Stainless Steel
FKM
1 second
IP65
Output
4-20 mA, 3-wire
Max Load
500 ohms
Power Supply
24 VDC ± 20%
Power Consumption
80 mA
Electrical Connection
Plug M12 x 1
Pulse Output
PNP, Open Collector, max. 200 mA 500 Hz at full scale
Power Supply
24 VDC ± 20%
Power Consumption
60 mA
Electrical Connection
Plug M12 x 1
| Categories | Title | Summary | File Size | Download |
|---|---|---|---|---|
| Data Sheets (PDF) | COBALT_DS-47X 2405 B.pdf | Latest data sheet for the COBALT Series (Model 47xx) | 2 MB |
